Xeon Scalable Processor - Single Socket Servers

Ideal business-class servers, the Broadberry CyberServe SP1 range of Single Xeon rackmount servers is based on the Intel Xeon Scalable Processor family.

Providing huge benefits in performance, efficiency and security, these single socket servers can be configured with up to 512GB DDR4 RAM and 22 processing cores.



CyberServe Xeon SP1-P04S

Single Scalable Processor, with lots of Expansion slots and High Capacity Drives - Ideal for SMB uses

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
3.5" Drives
Form Factor:
2U
Features:
VMware Compatible, Best Value, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £987.05
Configure
CyberServe Xeon SP1-104S

Redundant Power Option, Dedicated Remote Management port with IPMI & Remote KVM Management

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
3.5" Drives
Form Factor:
1U
Features:
VMware Compatible, Best Value
Max RAM Capacity:
1TB
from: £1,064.85
Configure
CyberServe Xeon SP1-108S

Redundant Power Option, Dedicated Remote Management port with IPMI & Remote KVM Management

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
2.5" Drives
Form Factor:
1U
Features:
VMware Compatible, Best Value, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £1,141.49
Configure
CyberServe Xeon SP1-208S

6 x PCIE Low Profile, Redundant Power Option, Dual Gigabit, 8+2 x Internal Drives, Dedicated LAN for IPMI Remote Management & Remote KVM

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
3.5" Drives
Form Factor:
2U
Features:
VMware Compatible, Best Value, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £1,146.21
Configure
Best Seller 3.5" Drives
CyberServe Xeon SP1-212S

Redundant Power, Dedicated Remote Management Port with Fully Featured IPMI & Remote KVM Management

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
3.5" Drives
Form Factor:
2U
Features:
VMware Compatible, Extra Expansion Slots, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £2,276.81
Configure
CyberServe Xeon SP1-224S

Redundant Power, Dedicated Remote Management Port with Fully Featured IPMI & Remote KVM Management

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
2.5" Drives
Form Factor:
2U
Features:
VMware Compatible, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £2,485.49
Configure
Ultra High-Performance 2.5" Drives
CyberServe Xeon SP - GA88B5631

4x PCIE x16, Redundant Power, Dual Gigabit, 2 Hot-Swap Drives

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
SATA
HDD Size:
2.5" Drives
Form Factor:
1U
Features:
VMware Compatible, Extra Expansion Slots, Redundant Power Supply Option
Max RAM Capacity:
1.5TB
from: £2,766.94
Configure
CyberServe Xeon SP1-424S

Redundant Power, Dedicated Remote Management Port with Fully Featured IPMI & Remote KVM Management

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
3.5" Drives
Form Factor:
4U
Features:
VMware Compatible, Extra Expansion Slots, Full Height/Length Expansion, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £3,034.15
Configure
CyberServe Xeon SP1-436S

24 + 12 Bays at Rear, Redundant Power, Dedicated Remote Management Port with IPMI & Remote KVM Management

Server Processor:
Xeon Scalable Processor - Single Socket
Drive Bays:
Hot-Swap Drives
Drive Interface:
12Gb/s SAS
HDD Size:
3.5" Drives
Form Factor:
4U
Features:
VMware Compatible, Extra Expansion Slots, Full Height/Length Expansion, Redundant Power Supply Option
Max RAM Capacity:
1TB
from: £3,246.88
Configure

Call a Broadberry Storage & Server Specialist Now: 020 8997 6000

Have a Broadberry Expert Contact You:

Boasting up to 22 cores, 112 threads and 96 lanes of PCIe, the Broadberry CyberServe SP1 range of rackmount server solutions is based on single Intel Xeon Scalable Processors. This makes them a superb choice for a huge variety of applications, ranging from business servers to mid-level applications.

CyberServe SP1® Servers are Ideal for:

Based on the Intel Xeon Processor Scalable family, capable of supporting up to 12 DIMMS per CPU and boasting an enhanced memory subsystem, the Broadberry CyberServe SP1 range of server solutions are optimised for these applications:

  • Business Servers
  • Domain Controllers
  • Virtualised Infrastructure
  • Cloud Servers

Re-designed from the ground up for huge improvements, the era-defining Intel Xeon SP Processor family goes above and beyond the standards set by previous generations (Intel Xeon E5 and E7 V4). Find more information on the Xeon Scalable range below.

Models Explained:
Entry

Ideal for smaller businesses, Intel Xeon Bronze processors are developed to work best with basic storage servers.

Entry

The Intel Xeon Silver is optimised for middling IT organisations that are still developing. It delivers the speed and security you need for your data centre.

Entry

Intel Xeon Gold processors provide high performance and high-level reliability. Featuring hardware-enhanced security, this option is ideal for demanding and high intensity workloads.

Entry

Intel Xeon Platinum processors provides arguably the best performance in the industry for mission critical and cloud workloads, AI, machine learning and real time analytics. It also delivers humungous leaps in I/O, memory, storage and network technologies.

up to 8 Cores up to 12 Cores up to 22 Cores up to 28 Cores
up to 2 Sockets up to 2 Sockets up to 4 Sockets up to 8+ Sockets
up to 1.5TB up to 1.5TB up to 6TB up to 12TB

The CyberServe Xeon-SP range of business class servers has been designed and built from the ground up for modern data centre applications.

Driven by the Intel Xeon Scalable processor family, these flexible servers are able to excel across applications. With this range you benefit from gaining insights from advanced real time analytics as well as emerging technologies such as AI, autonomous driving, 5G and many more.

Adding a server from this range to your data centre will allow you to enjoy the ability to take advantage of new opportunities discovered via advanced, data fuelled methods.

  • Skylake core microarchitecture, with enhancements specific to your data centre
  • Intel AVX-512 with 32 DP flops per core
  • Data centre optimised cache hierarchy -1MB L2 per core, non-inclusive L3
  • New mesh interconnect architecture
  • Enhanced memory subsystem
  • Modular IO with integrated devices
  • Intel Ultra Path Interconnect - (Intel UPI)
  • Intel Speed Shift Technology
  • Security & Virtualisation enhancements (MBE, PPK, MPX)
  • Optional Integrated Intel Omni-Path Fabric (Intel OPA)
Intel Xeon Processor E5-2600 v4 Intel Xeon Scalable Processor
Cores Per Socket Up to 22 Up to 28
Threads Per Socket Up to 44 threads Up to 56 threads
Last-level Cache (LLC) Up to 55 MB Up to 38.5 MB (non-inclusive)
QPI/UPI Speed (GT/s) 2x QPI channels @ 9.6 GT/s Up to 3x UPI @ 10.4 GT/s
PCIe* Lanes /Controllers /Speed(GT/s) 40 / 10 / PCIe 3.0 (2.5, 5. 8 (GT/s) 48 / 12 / PCIe 3.0 (2.5, 5,8 GT/s)
Memory Population 4 channels of up to 3 RDIMMs,
LRDIMMs, or 3DS LRDIMMs
6 channels of up to 2 RDIMMs,
LRDIMMs, or 3DS LRDIMMs
Max Memory Speed Up to 2400 Up to 2666
TDP (W) 55W-145W 70W-205W

Compute:
  • Intel AVX-512
  • Unified 2S/4S/8S
  • Up to 28 cores
  • New MLC arch
  • Speed Shift Technology
  • High Frequency SKUs
  • New on-die interconnect
IO:
  • More PCIe lanes (48)
  • Higher PCIe BW
  • Intel VMD
  • Intel VROC
  • Intel UPI @ 10.4GTs
  • 2S 3UPI support
  • NTB Improvements
  • PCIe Dual-Case
  • SRIS
Memory:
  • 6 Channels
  • Up to DDR4 2666MHz
  • ADR Improvements
  • 4S/8Sw/o Memory Buffers
Fabric:
  • Integrated Fabric
  • Saves 16 PCIe Lanes
  • OPA Switches
  • OPA Cards
Security:
  • Intel Boot Guard
  • SecurityPerf
  • PPI-X
  • Intel TXT Improvements
  • Intel BIOS Guard 2.0
  • Intel MPX

The CyberServe SP1 range is capable of supporting up to 12 DIMMS per CPU. That’s a significant advancement on the previous limit, which was 9 DIMMS per CPU, representing a 50% increase in memory bandwidth. In addition to this it also means a 10% speed boost per channel with the newly supported DDR4-2666 MHz memory.

On higher end models the platform is scalable up to 4 and 8 sockets as well as more I/O and memory bandwidth. With the new standards set by the leap in system capability it became clear that the time had come for Intel to replace the QPI. That replacement comes in the form of Intel Ultra Path Interconnect (Intel UPI).

The Xeon Scalable Processor family features breakthrough performance and possesses the industry leading memory and I/O capacity necessary to substantially eliminate performance bottlenecks. The Xeon Scalable performance is a big contributor to the strong performance of the overall system.

Applications can be accelerated via the addition of Intel QAT (Quick Assist Technology) to a software-defined infrastructure environment. Intel QAT offers noteworthy increases in the performance and efficiency of standard platform solutions.

The Intel Xeon Scalable processors the Broadberry CyberServe SP1 range is based on provide a degree of flexibility and performance that allows you to handle business server and hosting server demands.


Our Intel Xeon Scalable Processor based servers feature security without compromise, incorporating a number of technologies and features that will aid in safeguarding your system.

Intel Quick Assist Technology delivers a software-enabled base for security and authentication. Intel Key Protection Technology is found within Intel Xeon Scalable processors, enabled via Intel QAT. Intel KPT is on hand to help with secure private key management.

These features provide an immensely vital foundation for secure IT. They are necessary to handle the ever-increasing and evolving threats across both physical and virtual infrastructures.


As leading providers of enterprise grade server and storage solutions over the past three decades, we’ve supplied some of the world’s largest organisations including the likes of Sky, Toshiba, the University of Oxford, the University of Cambridge, Disney, the BBC, NASA and many more.

Our powerful online configurator allows you to create your CyberServe server to perfectly fit the needs and requirements of your business. With a wide array of features, hundreds of possible configuration combinations and a meticulous design process that optimises them directly for you, our servers are built to help your business thrive.

Our Rigorous Testing

Before leaving our UK workshop, all Broadberry server and storage solutions undergo a rigorous 48 hour testing procedure. This, along with the high-quality industry leading components we use ensure all of our server and storage solutions meet the strictest quality guidelines demanded from us.


Un-Equaled Flexibility

Our main objective is to offer great value, high-quality server and storage solutions, we understand that every company has different requirements and as such are able to offer un-equaled flexibility in designing custom server and storage solutions to meet our clients' needs.

Trusted by the World's Biggest Brands

We have established ourselves as one of the biggest storage providers in the UK, and since 1989 supplied our server and storage solutions to the world's biggest brands. Our customers include:
