Supermicro A+ Server 1013S-MTR | AS -1013S-MTR®

Configure a Supermicro A+ Server 1013S-MTR | AS -1013S-MTR

  • Web Hosting, VM
  • Cloud Computing
  • Connectivity/Storage    Computer Nodes
  • Single AMD EPYC™ 7000-Series Processor
  • Up to 1TB Registered ECC DDR4   2666MHz SDRAM in 8 DIMMs
  • 1 PCI-E 3.0 x16 (FH/HL) slot
  • Integrated IPMI 2.0 + KVM with   dedicated LAN
  • 2x 1GbE LAN ports via Intel I210
  • 4 hot-swap 3.5" SATA3 drive bays   or 4 SAS3 ports (SAS Add-on Card   is optional),   1 M.2 NVMe SSD Supported
  • 400W Redundant Platinum Level   Power Supplies   (Full redundancy based on configuration   and application load)

Configure From £933.45  or  Buy Now




Loading Configurator...

Prices for products are subject to change without notice.

Supermicro A+ Server 1013S-MTR | AS -1013S-MTR Specifications

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Advanced Security

AMD EPYC processors feature an embedded security processor, meaning full memory encryption without the need for any changes to your applications.

Higher Performance

The AMD EPYC processor family is an excellent option for HPC and has been built to promote balancing the ratio of cores, memory and I/O bandwidth.

World Record Speed

The AMD EPYC x86 SoC has set new performance world records on SPEC CPU floating point bench marks.

Configure With Single Processor

Designed for server applications where multi processors are not required. Single processors are an affordable, cost-effective and reliable option.

Configure With Up to 1TB Of RAM

Equipable with up to a massive 1TB of RAM, allowing for fast and efficient multi-tasking for the most demanding applications.

Featuring Redundant Power Supply

Coming with a redundant power supply, this system has a backup power source it can fall back on if the original power source were to fail.

Configure With Hot-Swap Drives

The Supermicro A+ Server 1013S-MTR | AS -1013S-MTR features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 3.5" Drives

Configure the Supermicro A+ Server 1013S-MTR | AS -1013S-MTR with 3.5" drives. These drives are more cost-effective, offer a larger storage capacity and offer more flexibility.

Integrated Dual Gigabit LAN

Featuring an Integrated Dual Gigabit LAN network adapter which delivers reliability and performance. This server is not vendor locked and features wide ranging hardware and software compatibility.


Product SKUs
AS -1013S-MTR
  • A+ Server 1013S-MTR
Motherboard
H11SSL-i
Processor/Chipset
CPU
  • Single AMD EPYC 7000-series Processor (up to 200W)
  • Socket SP3
Cores
  • Up to 32 Cores
Chipset
  • System on Chip (SoC)
System Memory
Memory Capacity
  • 8 DIMM slots
  • Supports up to 1TB Registered ECC DDR4 2666MHz SDRAM
  • 8-channel memory bus
Memory Type
  • DDR4 2666 MHz Registered ECC, 240-pin gold-plated DIMMs
DIMM Sizes
  • 4GB, 8GB, 16GB, 32GB, 64GB, 128GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
SATA
  • SATA3 (6 Gbps)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • Intel I210 Controller
VGA
  • ASPEED AST2500 BMC
Expansion Slots
1U
  • 1 PCI-E 3.0 x16 (FH/HL) slot
M.2
  • Interface: PCI-E 3.0 x4
  • Form factor: 2280, 22110
Input / Output
SATA
  • 4 SATA3 (6 Gbps) ports
LAN
  • 2x 1GbE LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 5 USB 3.0 ports (2 rear + 2 via header + 1 Type A)
  • 4 USB 2.0 ports (2 rear, 2 via header)
VGA
  • 1 VGA port
Others
  • 1 COM port (rear)
  • 2 SATA DOM power connector
  • TPM 1.2 header
System BIOS
BIOS Type
  • AMI 128Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1
Chassis
Form Factor
  • 1U
Model
  • CSE-813MFTQC-R407CB
Dimensions
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 19.85" (503mm)
Weight
  • Net Weight: 20 lbs (9.1 kg)
  • Gross Weight: 33 lbs (15.0 kg)
Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • 2x Network activity LEDs
  • System Overheat LED / Fan fail LED /
    UID LED
Drive Bays
Hot-swap
  • 4 hot-swap 3.5" SATA3 drive bays
Peripheral Drives
Optional
  • Optional 2.5" drive adapter
  • Optional slim DVD drive
Backplane
HDD Backplane
  • Supports 4 SATA3 3.5" HDD
System Cooling
Fans
  • 4x 40x28mm 4-pin PWM Cooling Fans
Air Shroud
  • 1 Air Shroud
AC/DC240V Input Redundant Power Supplies
400W 1U Redundant Power Supplies with PMbus
Total Output Power
  • 400W
Dimension
(W x H x L)
  • 54.5 x 40 x 220 mm
Input
  • 100 - 240Vac / 6.0 - 3.0A / 50-60Hz
  • 200 - 240Vdc / 3.4 - 3.2A (CCC Only)
+12V
  • Max: 33A / Min: 0.5A
+5V sb
  • Max: 3A / Min: 0A
Output Type
  • Gold Finger Connector Mating with Molex 45984-4343
Certification
UL/cUL/CB/CE/BSMI/CCC
Platinum Level Certified
PC Health Monitoring
CPU
  • Monitors CPU Core Voltages, +12V, +3.3V, +5V, +5V standby, 3.3V standby, VBAT
  • CPU switching voltage regulator
FAN
  • Up to 8-fan status tachometer monitoring
  • Up to eight 4-pin fan headers
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 8x Fan connectors
  • IC Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header
Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
    10C to 35C (50F to 95F)
  • Non-operating Temperature:
    -40C to 70C (-40F to 158F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)

A 1U Supermicro SuperServer based on 1x Intel AMD EPYC 7000 Series range of processors, the Supermicro A+ Server 1013S-MTR | AS -1013S-MTR is configurable with up to 4x Hot-Swap Drives drive bays, and designed for optimal performance with 8x 2666MHz, 2933MHz DDR4 memory sockets .

The Supermicro A+ Server 1013S-MTR | AS -1013S-MTR supports the Intel AMD EPYC family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro A+ Server 1013S-MTR | AS -1013S-MTR boasts 1 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro A+ Server 1013S-MTR | AS -1013S-MTR Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: AMD EPYC 7000 Series
  • Range: Supermicro UP Servers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 3.5" Drives
  • Maximum RAM Capacity: 1TB
