Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8®

An efficient system optimised for virtualisation, the Supermicro SYS-1019C-FHTN8 is configured with hot swap 2.5” drive bays.

  • uCPE Network Appliance
  • Network Security Appliance
  • Virtualization
  • Single Socket H4 (LGA 1151) supports Intel Xeon processor E-2100, 8th Gen. Intel Core™ i3 Processors, Intel Celeron, Intel Pentium
  • Intel C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz; 4 DIMM slots
  • 1 PCI-E 3.0 x16 (FHFL) slot
  • 2 Hot-swap 2.5" SATA3 drive bays, 2 Internal 2.5" SATA3 drive bays (SSD only)
  • M.2 Interface: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
  • 8 GbE LAN ports, 1 Dedicated IPMI LAN
  • 2 USB 3.1, 2 USB 2.0, 1 VGA
  • 350W AC-DC multiple output Platinum Level Power Supply

Configure From £849.89  or  Buy Now




Loading Configurator...

Prices for products are subject to change without notice.

Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 Specifications

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Up To 50% More Cores

Powered by the latest Intel Xeon E family of processors, featuring up to 50% more cores than previous generation Xeon processors.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon E processor range, delivering massive improvements in every metric over the previous generation processors.

Data Protection Technology

Security is substantially improved with Intel Data Protection Technology (with Advanced Encryption Standard New Instructions).

Ideal For Small Business

Systems based on Intel Xeon E processors enable your business to evolve while also delivering a constantly available solution to safeguard your data.

Configure With Up to 128GB of RAM

Equipable with up to 128GB of RAM, this system optimised for light to mid level processing and offers a superb performance to cost ratio.

Optimised For Virtualisation

Designed to excel at virtualisation. You can use virtual machines for testing, to save physical space, to reduce costs, for hardware for increased compatibility and more.

Configure With Hot-Swap Drives

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 2.5" Drives

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.

Eight LAN with Intel This server features aI210-AT

The Eight LAN with Intel I210-AT network adapter delivers high performance. This server is completely free from vendor lock-in and features wide ranging hardware and software compatibility.


The Supermicro SYS-1019C-FHTN8 is ideal for SMB. Configurable with up to 128GB of RAM, this system is perfect for light to mid-level processing, delivering impressive performance to cost-ratio. The server is made to excel at virtualisation and is powered by the revolutionary Intel Xeon E processor range which brings 50% more cores and huge improvements in every area in comparison to previous generation Xeon processors. This system is configurable with the high performance Eight LAN with Intel I210-AT network adapter.

Product SKUs
SYS-1019C-FHTN8
  • SuperServer 1019C-FHTN8 (Black)
Motherboard

Super X11SCM-LN8F
Processor
CPU
  • Single Socket H4 (LGA 1151),
    CPU TDP support up to 80W
  • Support Intel Xeon E-2100 processors,
    8th Gen. Intel Core i3 Processors,
    Intel Celeron, Intel Pentium
System Memory
Memory Capacity
  • 4 DIMM slots
  • Up to 128GB Unbuffered ECC UDIMM
Memory Type
  • 2666/2400/2133MHz ECC DDR4 SDRAM
DIMM Sizes
  • 32GB, 16GB, 8GB, 4GB
Note
  • 128GB system memory capacity will be available in 2019 through a published BIOS update.
On-Board Devices
Chipset
  • Intel C246 chipset
SATA
  • Intel C246 controller for SATA3 (6 Gbps) ports; RAID 0, 1, 5, 10
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • Eight LAN with Intel I210-AT
Video
  • VGA via Aspeed AST2500 BMC
Input / Output
SATA
  • 5 SATA3 (6Gbps) ports
LAN
  • 8 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 3.1 ports (front)
  • 2 USB 2.0 ports (front)
Video
  • 1 VGA port
Serial Port / Header
  • 1 COM port (option)
System BIOS
BIOS Type
  • UEFI 256Mb
Management
Software
  • Intel Node Manager
  • IPMI 2.0
  • NMI
  • SSM, SPM, SUM
  • Watch Dog
  • SuperDoctor 5
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-513BTQC-350B
Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 15" (381mm)
Package
  • 8" (H) x 24" (W) x 27" (D)
Weight
  • Gross Weight: 14.1 lbs (6.4 kg)
  • Net Weight: 10.0 lbs (4.54 kg)
Available Colors
  • Black front panel with silver chassis
Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • Network activity LEDs
  • System Information LED
Expansion Slots
PCI-Express
  • 1 PCI-E 3.0 x16 (FHFL) slot
M.2
  • M.2 Interface: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
Drive Bays
Hot-swap
  • 2 Hot-swap 2.5" SATA3 drive bays
Internal
  • 2 Internal 2.5" SATA3 drive bays (SSD only)
System Cooling
Fans
  • 4x 40x28mm 4-pin PWM fans (optional: 2 additional fans)
Power Supply
350W AC power supply w/ PFC
AC Voltage
  • 100-240 V, 50-60 Hz, 4.2-1.8 Amp
+5V
  • Max.: 15 Amp
  • Min.: 0.2 Amp
+5V standby
  • Max.: 3 Amp
  • Min.: 0 Amp
+12V
  • Max.: 29 Amp
  • Min.: 0.5 Amp
-12V
  • Max.: 0.2 Amp
  • Min.: 0 Amp
+3.3V
  • Max.: 12 Amp
  • Min.: 0.2 Amp
Certification Platinum Level Certified
Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
    0C to 40C (32F to 104F)
  • Non-operating Temperature:
    -40C to 70C (-40F to 158F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)

A 1U Supermicro SuperServer based on 1x Intel Xeon E-2100 range of processors, the Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 is configurable with up to 2x Hot-Swap Drives drive bays, and designed for optimal performance with 4x 2666MHz DDR4 memory sockets .

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 supports the Intel family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 boasts 1 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: Xeon E-2100
  • Range: Virtualisation Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 64GB
