Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 ®

Short depth and compact, the low noise and general purpose Supermicro SYS-1019C-HTN2 is configurable with 2 hot-swap 2.5” SATA3 drive bays.

  • Compact 1U Embedded
  • Video Surveillance
  • Network Security
  • Office Server, DVR/NVR
  • Digital Signage, POS
  • Single Socket H4 (LGA 1151) supports Intel 8th/9th Generation Core™ i9/ Core™ i7/Core™ i5/Core™ i3/ Pentium/Celeron series Processor, Intel Xeon E processor (Coffee Lake-S) Server/Workstation
  • Intel C246 chipset
  • 2 Hot-swap 2.5" SATA3 drive bays
  • Up to 64GB unbuffered ECC/non-ECC UDIMM, up to DDR4-2666MHz; 4 DIMM slots
  • 1 PCI-E 3.0 x16 (HHHL) slot, M.2 (M key, 22110/80, PCI-E 3.0 x4/SATA)
  • 2 GbE LAN ports, 1 dedicated IPMI LAN
  • 4 USB 3.1 (3 Type A, 1 Type C)
  • 2 DP, DVI-I, VGA, ALC 888S HD Audio
  • 200W Low Noise AC-DC Power Supply with PFC, Gold Certified

Configure From £757.13  or  Buy Now




Loading Configurator...

Prices for products are subject to change without notice.

Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 Specifications

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Up To 50% More Cores

Powered by the latest Intel Xeon E family of processors, featuring up to 50% more cores than previous generation Xeon processors.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon E processor range, delivering massive improvements in every metric over the previous generation processors.

Data Protection Technology

Security is substantially improved with Intel Data Protection Technology (with Advanced Encryption Standard New Instructions).

Ideal For Small Business

Systems based on Intel Xeon E processors enable your business to evolve while also delivering a constantly available solution to safeguard your data.

Configure With Single Processor

Designed for server applications where multi processors are not required. Single processors are an affordable, cost-effective and reliable option.

Configure with up to 64GB of RAM

Equipable with up to 64GB of RAM. It is optimised for light to mid level processing tasks and offers a superb performance to cost ratio.

Optimised For General Purpose

Optimised for general purpose, this server is very effective for consistent all around use. if you require a server that can perform a wide variety of tasks well, this server is for you.

Designed For Short Depth

Built for short depth, this server is very space efficient. Short Depth servers can be less than half the length of standard servers, perfect for situations where space is at a premium.

Configure With Hot-Swap Drives

The Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 2.5" Drives

The Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.


The Supermicro SYS-1019C-HTN2 is powered by the Intel Xeon E range enjoys increased performance over systems powered by older generation Xeon processors. The processor features up to 50% more cores than its counterparts and features like Intel Data Protection Technology only boost the overall security of the system. This server is optimised for general purpose and its cost-effective nature makes it perfect for SMBs.

Product SKUs
SYS-1019C-HTN2
  • SuperServer 1019C-HTN2 (Black)
Motherboard

Super X11SCZ-F
Processor
CPU
  • Single Socket H4 (LGA 1151),
    CPU TDP support up to 80W
  • Support Intel 8th/9th Generation Core i9/Core i7/Core i5/Core i3/Pentium/Celeron series Processor, Intel Xeon E processor (Coffee Lake-S) Server/Workstation
  • A graphic integrated CPU is required to have onboard video from the DVI and DP ports
System Memory
Memory Capacity
  • 4 DIMM slots
  • Up to 64GB Unbuffered ECC/non-ECC UDIMM
  • Up to DDR4-2666MHz
Memory Type
  • 2666/2400/2133MHz ECC DDR4 SDRAM
DIMM Sizes
  • 64GB, 32GB, 16GB, 8GB, 4GB
On-Board Devices
Chipset
  • Intel C246 chipset
SATA
  • SATA3 (6Gbps) via Intel C246 controller
  • RAID 0, 1 support
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • Single LAN with Intel I210-AT
  • Single LAN with Intel PHY I219LM
Video
  • ASPEED AST2500 BMC and Intel HD Graphics
Audio
  • ALC 888S 7.1 HD Audio
Input / Output
SATA
  • 2 SATA3 (6Gbps) ports; RAID 0, 1
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 3 USB 3.1 ports (3 Type A and 1 Type C)
Video/Display
  • 2 DP (DisplayPort): 1 DVI-I, 1 VGA D-Sub Connector port
  • 3 independent displays
Audio
  • MIC-in and LINE-out
TPM
  • TPM Header " Chip
System BIOS
BIOS Type
  • AMI UEFI
Management
Software
  • IPMI 2.0 with KVM support
  • Watch Dog
  • SuperDoctor 5
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-510FT-203B
Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 11.3" (287mm)
Package
  • 6.1" (H) x 25.4" (W) x 19.8" (D)
Weight
  • Gross Weight: 14.1 lbs (6.4 kg)
  • Net Weight: 10.0 lbs (4.54 kg)
Available Colors
  • Black
Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • 2 Network activity LEDs
  • System Information LED
Expansion Slots
PCI-Express
  • 1 PCI-E 3.0 x16 (HHHL) slot
M.2
  • M.2 Interface: 1 SATA/PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
Drive Bays
Internal
  • 2 Hot-swap 2.5" SATA3 drive bays
    (maximum 12mm-thick drive)
System Cooling
Fans
  • 4x 40x28mm 4-pin PWM fans
Power Supply
200W Low Noise AC-DC power supply with PFC
AC Voltage
  • 100 - 240V, 50-60Hz, 2.6 Amp Max
+5V
  • 8.0 Amp (max.)
+5V standby
  • 2.0 Amp (max.)
+12V
  • 16 Amp (max.)
-12V
  • 0.5 Amp (max.)
+3.3V
  • 8.0 Amp (max.)
Certification
Gold Certified
PC Health Monitoring
CPU
  • Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages.
FAN
  • Total of 6 fan headers supporting up to 6 fans
  • 6 fans with tachometer status monitoring
  • Status monitor for speed control
  • Status monitor for on/off control
  • Low noise fan speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU thermal trip support
  • I2C temperature sensing logic
  • Thermal Monitor 2 (TM2) support
  • PECI
Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
    10C to 40C (50F to 104F)
  • Non-operating Temperature:
    -40C to 70C (-40F to 158F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)

A 1U Supermicro SuperServer based on 1x Intel Xeon E-2100 range of processors, the Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 is configurable with up to 2x Hot-Swap Drives drive bays, and designed for optimal performance with 4x 2666MHz DDR4 memory sockets .

The Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 supports the Intel family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 boasts 1 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SYS-1019C-HTN2 SuperServer | 1019C-HTN2 Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: Xeon E-2100
  • Range: General Purpose Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 64GB
