Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L®

Configure a Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L

  • Entry level, Cost effective
  • Compact, less than 15" depth
  • Single Socket H4 (LGA 1151) supports Intel Xeon processor E-2100, 8th Gen. Intel Core™ i3 Processors, Intel Celeron, Intel Pentium
  • Intel C242 chipset
  • Up to 128GB ECC UDIMM, up to DDR4-2666MHz; 4 DIMM slots
  • 1 PCI-E 3.0 x16 slot
  • 2x 3.5" or 3x 2.5" drive bays with optional converter kits
  • M.2 Interface: 1 PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
  • 4 GbE LAN ports, 1 dedicated IPMI LAN
  • 2 USB 3.1 (rear), 2 USB 2.0 (rear)
  • 1 VGA, 1 COM, 1 TPM
  • 350W Multi-output power supply, Platinum Level Certified

Configure From £798.94  or  Buy Now




Loading Configurator...

Prices for products are subject to change without notice.

Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L Specifications

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Up To 50% More Cores

Powered by the latest Intel Xeon E family of processors, featuring up to 50% more cores than previous generation Xeon processors.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon E processor range, delivering massive improvements in every metric over the previous generation processors.

Data Protection Technology

Security is substantially improved with Intel Data Protection Technology (with Advanced Encryption Standard New Instructions).

Ideal For Small Business

Systems based on Intel Xeon E processors enable your business to evolve while also delivering a constantly available solution to safeguard your data.

Configure With Single Processor

Designed for server applications where multi processors are not required. Single processors are an affordable, cost-effective and reliable option.

Configure With Up to 128GB of RAM

Equipable with up to 128GB of RAM, this system optimised for light to mid level processing and offers a superb performance to cost ratio.

Entry Level Optimised Server

Perfect for smaller businesses, this server is optimised as an entry level server. The advantages of an entry level server include cost effectiveness.

Designed For Short Depth

Built for short depth, this server is very space efficient. Short Depth servers can be less than half the length of standard servers, perfect for situations where space is at a premium.

Configure With Fixed Drives

The Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L can be configured with reliable fixed drives which are a cheaper alternative to hot-swappable drives, lowering the overall cost of the system.

Configure with 2.5" Drives

The Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.

Integrated Quad Gigabit Ethernet

The integrated quad gigabit ethernet network adapter delivers performance and reliability. This server is free from vendor lock-in and features wide ranging hardware and software compatibility.


[[
Product SKUs
SYS-5019C-M4L
  • SuperServer 5019C-M4L (Black)
Motherboard

Super X11SCL-LN4F
Processor
CPU
  • Single Socket H4 (LGA 1151),
    CPU TDP support up to 95W
  • Support Intel Xeon Processor E-2100 series, 8th Gen. Intel Core i3 / Pentium / Celeron Processors
Cores
  • 6 cores, 12 threads
System Memory
Memory Capacity
  • 4 DIMM slots
  • Up to 128GB Unbuffered ECC UDIMM
  • Up to DDR4-2666MHz
Memory Type
  • 2666/2400/2133MHz ECC DDR4 SDRAM
DIMM Sizes
  • 32GB, 16GB, 8GB, 4GB
Note
  • 128GB system memory capacity will be available in 2019 through a published BIOS update.
On-Board Devices
Chipset
  • Intel C242 chipset
SATA
  • SATA3 (6Gbps) via Intel C242 controller
  • RAID 0, 1, 5, 10 support
IPMI
  • ASPEED AST2500
Network Controllers
  • Quad LAN with Intel I210-AT
Video
  • ASPEED AST2500 BMC
Input / Output
SATA
  • 6 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
LAN
  • 4 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 3.1 ports (rear)
  • 2 USB 2.0 ports (rear)
Video
  • 1 VGA port
Serial Port / Header
  • 1 COM port (header)
TPM
  • 1 TPM 2.0 Header
System BIOS
BIOS Type
  • UEFI 256Mb
BIOS Features
  • ACPI 6.0
  • SMBIOS 2.7
  • Plug and Play (PnP)
  • RTC (Real Time Clock) Wakeup
  • UEFI 2.7
  • USB Keyboard support
  • PCI 3.0
Management
Software
  • Intel Node Manager
  • IPMI 2.0
  • NMI
  • SSM, SPM, SUM
  • Watch Dog
  • SuperDoctor 5
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-512F-350B1
Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 14.5" (368mm)
Package
  • 6.3" (H) x 22" (W) x 20" (D)
Weight
  • Gross Weight: 17 lbs (7.71 kg)
  • Net Weight: 11 lbs (4.99 kg)
Available Colors
  • Black
Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • Network activity LEDs
  • System Information LED
Expansion Slots
PCI-Express
  • 1 PCI-E 3.0 x16 slot
M.2
  • M.2 Interface: 1 PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
Drive Bays
Internal
  • 2x 3.5" or 3x 2.5" drive bays with optional converter kits
System Cooling
Fans
  • 2x 4cm counter-rotating PWM fan
Power Supply
350W AC power supply w/ PFC
AC Voltage
  • 100-240 V, 50-60 Hz, 4.2-1.8 Amp
+5V
  • Max.: 15 Amp
  • Min.: 0.2 Amp
+5V standby
  • Max.: 3 Amp
  • Min.: 0 Amp
+12V
  • Max.: 29 Amp
  • Min.: 0.5 Amp
-12V
  • Max.: 0.2 Amp
  • Min.: 0 Amp
+3.3V
  • Max.: 12 Amp
  • Min.: 0.2 Amp
Certification Platinum Level Certified
PC Health Monitoring
CPU
  • Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages.
FAN
  • 6x 4-pin fan headers (up to 6 fans), 6 fans with tachometer status monitoring, Fan speed control, Overheat LED indication, Thermal control tachometer fan connectors
Temperature
  • Monitoring for CPU and chassis environment, CPU thermal trip support, Thermal Monitor 2 (TM2) support, PECI
Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
    10C to 35C (50F to 95F)
  • Non-operating Temperature:
    -40C to 70C (-40F to 158F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)
]]

A 1U Supermicro SuperServer based on 1x Intel Xeon E-2100 range of processors, the Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L is configurable with up to 3x Fixed Drives drive bays, and designed for optimal performance with 4x 2666MHz DDR4 memory sockets .

The Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L supports the Intel family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L boasts 1 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SuperServer 5019C-M4L | SYS-5019C-M4L Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: Xeon E-2100
  • Range: Entry Level Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Fixed Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 64GB
